Plumbing and Pipe Fitting 3, WASSCE (SC), 2016

Question 2

The following materials have been provided for this exercise:



            (a)        one 1500 mm length of 19 mm PVC pipe;
(b)        four 19 mm PVC elbow;
(c)        two 19 mm air valves;
(d)       one 19 mm brass tap;
(e)        one 13 mm nipple PVC;
(f)        one 19 mm x 13 mm reducing socket;
(g)        one tin of tangit gum;
(h)        one 13 mm shower rose;
(i)         one 19 mm PVC tee.
Using the materials supplied, construct a long screw joint with elbow and a short cut-off pipe as shown in the diagram below.

Observation

Most of the candidates performed very well in this question.
