Plumbing and Pipe Fitting 3, WASSCE (SC), 2016

Question 3

The following materials have been provided for this exercise:


  1. one 1100 mm length of 19 mm galvanized iron pipe;
  1. four 19 mm galvanized iron elbows;



  1. one 19 mm galvanized iron union connector.

Using screw tight jointing technique, cut and fix a length of 19 mm galvanized iron pipe as shown in Fig. 3.

Observation

Most of the candidates performed very well in this question.
