building construction Paper 2 WASSCE (PC), 2016

Question 5



            (a)        State two functions of a road kerb.
(b)        State three factors that influence the choice of material for pavement works.
(c)        Sketch in elevation a wooden close-boarded fence and label the following parts:
(i) post;
(ii)  top rail

(iii) batten

.



Observation



Majority of candidates were able to:
-           state two functions of a road kerb;
-           state three factors that influences the choice of materials for pavement works.
However, few of the candidates were not able to:

  • sketch in elevation a wooden close-boarded fence;
  • label the parts of  a wooden close-boarded fence correctly.

The expected response to question 5 is as given below:



.(a)      Two functions of a road Kerb:

(i)         kerb resists the lateral thrust of the traffic on it;
(ii)        kerb is also used to guide traffic;
(iii)       kerb is used on dual carriageway to protect the pedestrians from vehicle;
(iv)      kerb defines carriageway limits;
(iv)      kerb directs the flow of surface water to gullies.



   b)          Three factors that influence the choice of materials for pavement works:


  • material cost;
  • maintenance cost;
  • appearance;
  • wear-resistance properties;
  • strength/durability;
  • weather resistance;
  • non-slip properties.
  • traffic volume;
  • traffic characteristics.



  (c)      Sketch of a close-boarded wooden fence
