General Mathematics Paper 2, WASSCE (PC), 2022

Question 5

  1. A bird perches on the top of a slanted tree of length 12.8 m. If the bird is 10 m vertically above the ground,

(i) illustrate the information in a diagram;
(ii) find, correct to the nearest degree, the angle of depression of the foot of the tree
from the bird



  1. The table shows the distribution of marks obtained by some students in a test.

Marks

1

2

3

4

5

6

7

8

9

Number    of students

11

12

10

17

16

15

14

13

12


If a student is selected at random from the class, find the probability that the student
obtained at most 7 marks.



Observation



The Chief Examiner reported that some of the candidates who attempted part (a) of this question did not quite understand the question as a result could not draw the correct diagram. The part (b) of this question was also not well attempted as some candidates could not interpret the idea at most 7 marks.
In part (a), they were expected to draw the diagram as shown:
