Building Construction Paper 1,Nov/Dec. 2009
Questions:   1 2 3 4   Main
General Comments
Weakness/Remedies
Strength
Specifications





Question 1

To a scale of 1:50, draw a detailed section Y – Y of the building from foundation to the roof.



_____________________________________________________________________________________________________
OBSERVATION

Most candidates were able to:

-           complete the drawing from foundation to the roof;
-           produce good pencil work;
-           show the base line of the hardcore below the natural ground level.

However, some of them failed to:

-           use the correct strip foundation type;
-           use the correct symbol to represent the hardcore;
-           construct the semi-circular arches;
-           label the roof members.

The detailed section Y – Y of the building from foundation to the roof is as shown on page 366.
