Building Construction Paper 1,Nov/Dec. 2009
Questions:   1 2 3 4   Main
General Comments
Weakness/Remedies
Strength


















Question 3

Draw, to a scale of 1:100, the following views of the building:

(a)        front elevation;
(b)        right side elevation (East view).


_____________________________________________________________________________________________________
OBSERVATION

Most candidates were able to:

-           distinguish the floor from the ground level;
-           locate the positions of the doors and windows;
-           show the number of bays for the doors and windows.

However, they failed to:

-           construct the semi-circular arches;
-           show the metal balustrade at the verandah;
-           show the recessed wall on the right side view.

The respective front and right side elevations of the building are as shown on the next page.
