Building Construction Paper 1, May/June. 2013
Questions:   1 2 3 4   Main
General Comments
Strength
Weakness/Remedies
Specification
Question 1

Draw to a scale of 1:50, the detailed section A – A of the building from foundation to roof.

_____________________________________________________________________________________________________
Observation
 Most candidates were able to:

-           show the complete timber roof structure;
-           label all the members correctly.

However, some of the candidates failed to:

-           show the compacted earth filling;
-           draw the correct door type (i.e. flush door);
-           represent the walls in section with 45º hatch lines.

The expected response to question 1 is as given below:
