Question 4

Complete the construction of the involute of a triangle below.





_____________________________________________________________________________________________________
Observation

The Involute of a triangle is obtained by a radiating a line from each apex of the triangle stepwise in ratio 1 :2:3. With point 0 as the starting point a smooth curve is drawn as shown below. A good number of the candidates did well in this question
